*Over View
|
HS CODE ( Korea) |
8414 10, 8414 90 |
|
PORT (By sea) |
Busan port, Incheon port |
|
PORT (By air) |
Incheon airport |
|
MOQ |
OVER 1SET VACUUM PUMP |
|
INCOTERMS |
FOB, CFR, CIF |
|
PACKING (BY SEA) |
INTERNATIONAL STANDARD SEA -WORTHY PACKAGING |
|
PACKING (BY AIR) |
INTERNATIONAL STANDARD AIR-CARTON BOX |
|
DELIVERY PERIOD(COMMON PUMP) |
WITHIN 1 WEEK FROM FACTORY TO PORT |
|
PAYMENT |
T/T IN ADVANCE, L/C |
1. DESIGN FEATURE
– Due to the system stadarization of all pump parts and inspectation of material directly by our QC team, we can guarantee and make excellent ultimate vacuum and long durability of pump
–With only 1(one) wrench without other tools, the user can disassemble and overhaul pump. And through huge sight glass(Max 72Ø/MVP-90) and drain plug, simple maintenance and oil replacement.
–Imporved oil anti-suckback system to protect the vacuum system in the event of sudden stop
-Occupying international stadard clamp, and flange (DN25 KF, DN 40 KF) at inlet and outlet port to assemble and make system easily
-Low noise(below 56dB) and vibration
–By using 3 stage of Gas ballast, the user can control mist (high, low and without mist stage)
2. Technical Data
|
Description |
Unit |
MVP-6 |
MVP-12 |
MVP-24 |
MVP-36 |
MVP-60 |
MVP-90 |
|
|
Displacement speed (50Hz) |
L/Min |
80 |
170 |
335 |
500 |
830 |
1250 |
|
|
m3/h |
5 |
10 |
20 |
30 |
50 |
75 |
||
|
Ultimate Pressure |
Gas ballast C |
Torr |
5 X 10-4 |
|||||
|
Gas ballast I |
5X10-3 |
|||||||
|
Gas ballast II |
5X10-2 |
|||||||
|
Water Vapour tolerance |
Torr |
40 |
40 |
25 |
25 |
40 |
40 |
|
|
Oil Filling |
L |
1.1 |
1.2 |
2.0 |
2.3 |
4.5 |
6.5 |
|
|
Inlet port |
DN |
25KF |
40KF |
|||||
|
Outlet port |
DN |
25KF |
40KF |
|||||
|
Motor power |
kW |
0.4 |
0.75 |
1.5 |
2.2 |
|||
|
Rotational speed of pump |
R.P.M |
1450 |
||||||
|
Noise Level (without gas ballast) |
dB |
50 |
50 |
52 |
52 |
56 |
56 |
|
|
Weight |
KG |
21 |
22.5 |
38 |
41 |
68 |
84 |
|
